| Pitch/mm |
P6.25 |
| Pixel Density/(dots/m2) |
25600 |
| LED Configuration |
1R1G1B |
| Led Type |
SMD3535 |
| Scan Driver |
1/10 scan |
| View angle / ° |
V120/H150 |
| Average power consumption/W/M2 |
250W |
| Max power consumption/W/M2 |
800W |
| Module size/mm |
250*250mm |
| Module Resolution/Pixels |
40*40 |
| Size of cabinet/mm |
500*500mm/500*1000mm*75mm(thickness) |
| Refresh rate Hz/S |
≥1920 |
| Luminance of white balance |
≥4500nits |
| Best Viewing Distance/m |
6.5-30m |
| Operation of Environmental Temperature/°C |
-20 ~ 50 |
| IP rating |
Front:IP65; Rear:IP54 |
| Working vlotage |
110-220 VAC/+/- 10% ; 50~60HZ |
| Grey scale/color |
displaying colors≥16.7M(synchronized) |
| Brightness adjustment |
256 levels of each color(manually),100 levels of each color(automatically) |
| Input signal |
RF,S-Video,RGB,RGBH,YUV,YC&Composition,etc |
| Control system |
linsn(sending card,receiving cards and Hubs);Nova |
| Average of non-failure life |
>50,000 hours |
| Life span |
>100,000hours |
| Functionaless dot rate |
<0.0001 |
