EVERSHINE OPTO LIMITED

Product Advantages:

1) Reliable quality, advanced and mature technology, compliant with industrial   standards
2) Good heat emission, water proof and stable performance
3) and video interface of the system can offer vivid, complete and high   quality LED display to TV broadcasting signal
4) High resolution and definition of screen image, clear and non-flash screen    image
5) Supports video and radio frequency input, special structure can be freely   assembled

Parameter	Unit	Value
Pitch	mm	5
Brightness	nits	4,500
Color temperature	deg. K	6,500
Viewing angle - Horizontal (50% brightness)	deg.	130 (+65/-65)
Viewing angle - Vertical (50% brightness)	deg.	60(+30/-30)
Tube chip color		Full color
Panel width	mm	1650
Panel height	mm	380
Panel depth	mm	75
Panel area	sq. m.	0.512
Panel material		Epoxy paint coated aluminum
Service acess		Front open
Ingress protection (front/rear)	IP	IP43
Operating temperature range	deg. C	-30 to +60
Humidity operating	RH	10% ~ 90%
Pixel type and configuration	R/G/B	3in1 SMD
Resolution per panel	Wide x High	320x64
Dot per panel	Pixels	20,480
LED per sq. meter	Pixels	40,000
Recommended minimum viewing distance	m	3.8
Recommended best viewing distance	m	4~40
Colors		281 Trillion
Grey scale (linear)	Levels	65,536 levels per color
Brightness control	Levels	Support (Add brightness sensor)
Processing depth	bit	16
Video frame rate	Hertz	60
Display refresh rate	Hertz	180~3,000
Input voltage (nominal)	VDC	12~24
Input power frequency	Hertz	50 to 60
Input power (max)	Watts / cabinet	500
Input power (typical)	Watts / cabinet	320
